Specification
Operating Range
-
-40° to 60°C (-40° to 140°F); no remote communications for battery voltage less than 3.9 V DC
Smart Sensor Connectors: 10
Smart Sensor Network Cable Length: 100 m (328 ft) maximum
Smart Sensor Data Channels:Maximum of 15 (some smart sensors use more than one data channel; see sensor manual for details)
Module Slots: 2
Logging Rate:1 second (RX3001 and RX3002) or 1 minute (RX3003 and RX3004) to 18 hours
Time Accuracy
-
±8 seconds per month in 0° to 40°C (32°F to 104°F) range;
±30 seconds per month in -40° to 60°C (-40° to 140°F) range
Battery Type/Power Source
-
4 Volt, 10 AHr, rechargeable sealed lead-acid; external power required using one of these options: AC power adapter (AC-U30), solar panel (SOLAR-xW), or external power source 5 V DC to 17 V DC with external DC power cable (CABLE-RX-PWR)
Rechargeable Battery Service Life
-
Typical 3–5 years when operated in the temperature range -20° to 40°C (-4°F to 104°F); operation outside this range will reduce the battery service life
Memory
-
32 MB, 2 million measurements, continuous logging
Alarm Notification Latency
-
Logging interval plus 2–4 minutes, typical
Enclosure Access
-
Hinged door secured by two latches with eyelets for use with user-supplied padlocks
LCD
-
LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or go blank in temperatures outside this range
Materials
-
Outer enclosure: Polycarbonate/PBT blend with stainless steel hinge pins and brass inserts; Inner enclosure: Polycarbonate; Gaskets: Silicone rubber; Cable channel: EPDM rubber; Cable opening cover: Aluminum with ABS plastic thumb screws; U-Bolts: Steel with zinc dichromate finish
Size
-
18.6 x 18.1 x 11.8 cm7.3 x 7.1 x 4.7 in.
Weight
-
2.2 kg4.85 lb
Mounting
-
3.8 cm (1.5 inch) mast or wall mount
Environmental Rating
-
Weatherproof enclosure, NEMA 4X (requires proper installation of cable channel system)
Wireless Radio
-
RX3003:
GSM/GPRS/EDGE: Quad band 850/900/1800/1900 MHz, UMTS/HSPA+: Five band 800/850/900/1900/2100 MHzRX3004:
GSM/GPRS/EDGE: Quad band 850/900/1800/1900 MHz
UMTS/HSPA+: Seven band 800/850/900/1800/1900/2100 MHz
LTE: Twelve Band 700/800/850/900/1800/1900/2100/2600 MHz
Antenna
-
RX3003: Penta band
RX3004: 4G LTE
