Description
Description
Features:
- Easy to read (0.8”) High bright Red LED Display
- Rugged construction suitable for industrial environment.
- With AC/DC supply power , built in rechargeable battery
- Heavy duty , environmentally protected load cell
- Anti shock
- Moveable
- Features and specification of indicator, see the catalog of the indicator
- According the function have 6 option model indicator : A7 / A12E / A1+p / A9+p / A15E / 315A1
Specification
| SPECIFICATION | PLATFORM SIZE | |||||
| 540 x 380 mm | 650 x 500 mm | 650 x 600 mm | ||||
| Capacity & Division | 150kg x 0.05kg | 300kg x 0.1kg | 300kg x 0.1 kg | |||
| – | 500kg x 0.1kg | 500kg x 0.1kg | ||||
| – | – | 600kg x 0.2kg | ||||
| Pan Size (W x L x H) mm | 540 x 380 x 190 | 650 x 500 x 195 | 650 x 600 x210 | |||
| Shape Size (W x L x H) mm | 480 x 735 x 1555 | 620 x 865 x 1160 | 720 x 860 x 1175 | |||
| Packing body size (W x L x H) mm | 800 x 490 x 330 | 890 x 600 x 360 | 900 x 700 x390 | |||
| Carton Indicator size (W x L x H) mm | 310 x 210 x 220 | 310 x 210 x 220 | 310 x 210 x 220 | |||
| Gross weight / pcs (kg) | 42 | 57.6 | 67 | |||
