CI 200S/SC Bench Scale
CAS

CI 200S/SC Bench Scale

Overview

Bench scale CI-200S / CI-200SC dari CAS berbahan stainless steel penuh dengan load cell stainless dan indikator IP67.

Fitur Utama

  • Konstruksi stainless steel penuh; load cell stainless steel
  • Indikator IP67 dengan display LED berkecerahan tinggi
  • Konektor kedap air untuk RS-232 dan kabel daya
  • Lampu komparator kuning/hijau/merah (CI-200SC)
  • Interface RS-232C; lampu komparator opsional
  • Kelas III dengan 10.000 divisi (NTEP 11-026), enclosure stainless 304 IP67 untuk CI-200SC
Tanya via WhatsApp
Merk
CAS
Kategori
Bench Scale

Spesifikasi & Penerapan

Aplikasi
Logistic & Storage

Detail Produk

Specification Value
Specification
Models CI-200S, CI-200SC
Construction All stainless steel; stainless steel load cell
Indicator Enclosure IP67 (CI-200SC: 304 stainless steel IP67)
Display 6-digit, 1-inch LED
Interface RS-232C, waterproof connector for RS-232 and power cable
Comparator Lamp Yellow / green / red (CI-200SC); optional on others
Operating Temperature -10°C to 40°C
Accuracy Class Class III, 10,000 divisions (NTEP 11-026)
Capacity / e (OIML pairing) CI-200S: 6 kg (0.002), 15 kg (0.005), 30 kg (0.01), 60 kg (0.02), 150 kg (0.05)
CI-200SC: 6 kg (0.002), 15 kg (0.005), 30 kg (0.01), 60 kg (0.02)
