Description
Features:
-
High-Torque Output
-
Delivers 2.7 N·m holding torque for demanding applications.
-
-
Precision Engineering
-
1.8° step angle with optional microstepping (via compatible driver).
-
-
Robust Construction
-
NEMA 23 frame with keyed shaft for secure coupling.
-
-
Thermal Management
-
Class B insulation withstands high temperatures.
-
-
Dual Bearing Support
-
Front/Rear ball bearings for extended lifespan under load.
-
-
Industry-Standard Mounting
-
NEMA 23 flange pattern (47.14mm bolt circle).
-
-
Dust Protection
-
IP50 rating for industrial environments.
-
Specification
1. Motor Specifications
-
Motor Type: 2-phase hybrid stepper motor
-
Frame Size: NEMA 23 (57mm square)
-
Step Angle: 1.8° (200 steps/revolution)
-
Holding Torque: 2.7 N·m (382 oz-in)
-
Rated Current: 2.4A/phase
-
Resistance: 1.5Ω/phase ±10%
-
Inductance: 6.5 mH/phase ±20%
-
Rotor Inertia: 480 g·cm²
-
Weight: 1.8 kg
2. Electrical Characteristics
-
Voltage Rating: 24VDC (recommended driver supply)
-
Temperature Rise: ≤80°C (at rated current)
-
Insulation Class: Class B (130°C)
3. Mechanical Specifications
-
Shaft Type: Single shaft with keyway (D-cut)
-
Shaft Diameter: 6.35mm (1/4")
-
Shaft Length: 30mm
-
Backlash: ≤0.1°
-
Bearing Type: Double-shielded ball bearings
4. Environmental Ratings
-
Operating Temp.: -10°C to +50°C
-
Storage Temp.: -20°C to +65°C
-
Humidity: 20-85% RH (non-condensing)
-
Protection Class: IP50 (dust-protected)
