WEW-100D 100Kn 10Ton Computer Display Hydraulic Universal Testing Machine
HST

WEW-100D 100Kn 10Ton Computer Display Hydraulic Universal Testing Machine

Overview

Mesin uji universal hidrolik untuk uji tarik, tekan, lentur, dan geser material logam dengan tampilan komputer. Kapasitas 100 kN (10 ton), empat kolom dua sekrup dengan tampilan komputer.

Fitur Utama

  • Kapasitas 100 kN, akurasi beban ≤ ±0,5%
  • Struktur 4 kolom 2 sekrup; resolusi perpindahan 0,0025 mm
  • Langkah piston 250 mm; kecepatan piston 0–150 mm/menit
  • Ruang tarik 780 mm dan ruang tekan 550 mm (dapat dikustomisasi)
  • Klem hidrolik; bulat Φ10–Φ32 mm (Φ4–Φ10 opsional), pipih 0–15 mm
  • Catu daya 3 fase AC 380 V 50 Hz
Tanya via WhatsApp
Merk
HST
Kategori
Hydraulic Universal Testing Machine

Detail Produk

Specification Value
Specification
Model (spec table) HST WEW-100E (page title: WEW-100D)
Structure 4 columns and 2 screws
Control Way Computer display
Max. Load 100 kN
Load Accuracy ≤ ±0.5%
Load Range 1% ~ 100% FS
Load Resolution 1/500000
Deformation Measurement Range 1% ~ 100% FS
Deformation Accuracy ≤ ±1%
Displacement Resolution 0.0025 mm
Displacement Error ≤ ±0.5%
Max. Piston Stroke 250 mm
Max. Piston Moving Speed 0-150 mm/min, stepless adjustment
Crosshead Lifting Speed 220 mm/min
Max. Tension Test Space 780 mm (customizable)
Max. Compression Test Space 550 mm (customizable)
Column Clearance 485 mm
Clamping Method Hydraulic clamp
Round Specimen Clamping Range Φ10-Φ20, Φ20-Φ32 mm (Φ4-Φ10 optional)
Flat Specimen Clamping Range 0-15 mm (15-30 optional)
Flat Specimen Clamping Width 80 mm
Compression Plate Size Φ160 mm
Bending Roller Distance 450 mm
Width of Bending Rollers 120 mm
Power Supply 3-phase, AC 380V, 50Hz (can be customized)
Standards ISO 6892, BS 4449, ASTM C39, ISO 7500-1, ASTM A370, ASTM E4, ASTM E8, BS EN standards
