Manual Bottle Cap Torque Tester NJY-20
Saicheng

Manual Bottle Cap Torque Tester NJY-20

Overview

Alat uji torsi tutup botol manual untuk mengukur gaya pembukaan dan gaya penguncian tutup pada botol, kantong bermulut (spout bag), dan kemasan tabung fleksibel.

Fitur Utama

  • Kapasitas sensor 20 Nm (standar); 5 Nm dan 40 Nm opsional, akurasi 0,5% FS
  • Dua mode pengukuran: gaya penguncian dan gaya pembukaan
  • Rentang jepit Φ5–Φ190 mm
  • Satuan uji dapat diganti tanpa konversi manual; jumlah uji dan statistik dapat diatur
  • Nol otomatis, peringatan kesalahan, dan proteksi overload
  • Layar sentuh 7 inci, printer mikro, dan port RS232
Tanya via WhatsApp
Merk
Saicheng
Kategori
Strength & Durability Tester

Detail Produk

Specification Value
Specification
Load Cell Capacity 20 Nm (standard); 5 Nm, 40 Nm (optional)
Accuracy 0.5% FS
Resolution 0.001 Nm
Clamp Range Φ5 mm ~ Φ190 mm (diameter)
Power Supply AC 100-240V 50/60Hz (can be changed to local requirement)
Instrument Dimension 310 mm (W) x 390 mm (D) x 320 mm (H)
Net Weight 17 kg
Test Standards ASTM D2063, ASTM D3198, ASTM D3474, GB/T 17876, BB/T 0025, BB/T 0034, YBB00392003-2015
Configuration
Standard Instrument, micro printer
Optional Professional software, 485 communication cable
