Data logger tahan cuaca dengan sensor suhu dan kelembapan relatif (RH) eksternal, untuk lingkungan luar ruangan atau area yang cukup keras. Setup dan unduh data dilakukan nirkabel lewat Bluetooth, tanpa membuka casing.
| Specification | Value |
|---|---|
| Temperature Sensor | |
| Range | -40° to 70°C (external sensor) |
| Accuracy | ±0.25°C from -40° to 0°C; ±0.2°C from 0° to 70°C |
| Resolution | 0.04°C |
| Drift | <0.01°C per year |
| Response Time (90%) | Depends on the external sensor used |
| RH Sensor | |
| Range | 0 to 100% RH, -40° to 70°C |
| Accuracy | ±2.5% from 10% to 90% typical, max ±3.5% including hysteresis at 25°C; below 10% and above 90% ±5% typical |
| Resolution | 0.01% |
| Drift | <1% per year typical |
| Response Time (90%) | Depends on the external sensor used |
| Logger | |
| Wireless Data Standard | Bluetooth Low Energy; approx. 30.5 m line-of-sight |
| Radio Power | 1 mW (0 dBm) |
| Logger Operating Range | -40° to 70°C |
| Logging Rate | 1 second to 18 hours |
| Logging Modes | Fixed interval (normal, statistics) or burst |
| Memory Modes | Wrap when full or stop when full |
| Start Modes | Immediate, push button, date & time, or next interval |
| Stop Modes | When memory full, push button, date & time, or after a set logging period |
| Time Accuracy | ±1 minute per month, 0° to 50°C |
| Battery | 2/3 AA 3.6 V lithium, user replaceable |
| Battery Life | 2 years (Power Saving Mode disabled); 5 years (Power Saving Mode enabled), 1-minute logging |
| Memory | 128 KB (63,488 measurements, maximum) |
| Full Memory Download Time | Approx. 60 seconds |
| Physical | |
| Logger Housing | 10.8 x 5.08 x 2.24 cm |
| External T/RH Sensor | 1.17 cm diameter; cable 2 m (6.56 ft) |
| Weight | Logger 75.5 g |
| Materials | Acetal, silicone gasket, stainless steel screws |
| Environmental Rating | NEMA 6 and IP67 |
