HOBO MX2202 Pendant Temperature Data Logger
HOBO

HOBO MX2202 Pendant Temperature Data Logger

Overview

Logger kecil tahan air untuk suhu dan intensitas cahaya (model MX2202), dengan akses nirkabel Bluetooth ke ponsel atau komputer Windows. Dapat dipakai di dalam ruangan, di luar ruangan, dan di air tawar maupun air asin.

Fitur Utama

  • Mengukur suhu dan cahaya (MX2202); MX2201 hanya suhu
  • Unduh data nirkabel lewat Bluetooth Low Energy ke aplikasi HOBOmobile
  • Tahan air sampai 30,5 m (100 ft)
  • Alarm, statistik, dan pencatatan burst yang dapat diatur
  • Memori 96.000 pengukuran
  • Baterai CR2032 yang dapat diganti pengguna
Tanya via WhatsApp
Merk
HOBO
Kategori
Water Temperature Logger

Spesifikasi & Penerapan

Aplikasi
Environment Oceanography

Detail Produk

Specification Value
Temperature Sensor (MX2201 and MX2202)
Range -20° to 70°C in air; -20° to 50°C in water
Accuracy ±0.5°C from -20° to 70°C
Resolution 0.04°C
Drift <0.1°C per year
Response Time (90%) 17 minutes in air moving 1 m/s; 7 minutes in stirred water (unmounted)
Light Sensor (MX2202)
Range 0 to 167,731 lux (15,582 lum/ft²)
Accuracy ±10% typical for direct sunlight
Logger
Wireless Data Standard Bluetooth Low Energy; approx. 30.5 m line-of-sight
Logging Rate 1 second to 18 hours
Time Accuracy ±1 minute per month at 25°C
Battery CR2032 3 V lithium, user replaceable
Battery Life 1 year (Bluetooth always on); 2 years (Bluetooth always off), 1-minute logging
Memory 96,000 measurements
Full Memory Download Time Approx. 45 seconds
Physical
Waterproof To 30.5 m (100 ft)
Dimensions 3.35 x 5.64 x 1.6 cm
Weight 12.75 g
Buoyancy (fresh water) 2 g positive
Wetted Materials Polypropylene case, EPDM O-ring
