Description
Description
Features:
- Easy-to-read 38mm LED display
- Alumunium die-casting enclosure
- High capacity rechargeable battery for crane
- Built in RS-232
Option :
- Extra display (wireless)
Specification
- Model : Caston (THZ) series.
- Max. capacity (kg) : 1.000, 2.000, 3.000, 5.000, 10.000, 20.000
- Readability (kg) : 0.5, 1.2, 2,5, 10
- External resolution : 1/2.000, 1/2.000, 1/3/000, 1/2.500, 1/2.000, 1/2.000
- Keys : ON/OFF, ZERO, TARE, HOLD
- Fuction : Auto off set, low voltage alarm, resolution switch
- Display type : 25mm ultra-luminance LED
- Operating temperature : -10oC ~+80oC
- Power : 6V/100AH (PB BATTERY) (for crane scale)
- Dimensions (mm) : 230(W) x 350(D) x 420(H) – 2ton, 230(W) x 350(D) x 585(H) 5 ton,
230(W) x 350(D) x 770(H) 10 ton, 230(W) x 350(D) x 950(H) 20 ton
- Product weight : 36: 2 ton, 35: 5 ton, 67: 10 ton, 98: 20 ton
